NOS C2 Corvette Clutch and Brake Pedals and Parts - $525 (Springfield)
QR Code Link to This Post
NOS Brake Pedal. For manual brakes for 1963-1966. GM PN 3830507/3908155 (Gr. 4.625).
NOS Spring. Return spring fits around brake pedal pivot. GM PN 3815814/3854322 (Gr. 0.837). Have 3.
Bushing, Brake Pedal. For brake pedal return spring. 1963-1967. GM PN 3830966 (Gr. 4.626). Have 2 used.
NOS Bushing, Clutch Pedal. 1963 - 1971. For ends of dash brace assembly (housing). 2 required. GM PN 3788356/3965692/4004821 (Gr. 0.831). Have 2 plus 5 used.
NOS Retainer. For clutch pedal end after assembly. 1963 - 1973. GM PN 3817880/3828428 (Gr 0.837). Have 3.
NOS Bumper. Top of clutch pedal stop. GM PN 3723230 (Gr. 0.829). Have 4.
NOS Clip. End of clutch pin and pushrod. GM PN 3712389/3749084 (Gr. 0.787). Have 5 plus 2 used.
All the above items are included in the price shown. One of each except Bushing 4004821 - 2.
May negotiate price if can find same GM NOS PNs in original GM packaging and in same condition for less.
________________________________________________________________
NOTES. I have many additional NOS linkage parts, used 1963 originals and Shark Bite aftermarket parts. NOT included in above price. Some NOS packaging included multiple parts but that is how GM sold them. See last photo for Word document listing all the parts that I have. I will send a copy of the document to your smart phone that can be enlarged to full size if requested.
I will set prices for parts as requested.
Pin Plate Bracket Assy. for clutch pedal. Used and usable. Purchased from LICS (Long Island Corvette Supply). Price $45.00. Price negotiable.
Clutch Pedal without pin plate bracket. 1963 - 1866 cars. Reinforcement piece added and welded to repair crack. Have 2. Price $125.00 each. See photos.
